Koyo ML1204 deep groove ball bearing

Koyo ML1204 deep groove ball bearing: bore d 1.2 mm, outside diameter D 4 mm, width 1.8 mm.

Deep groove ball bearings · All Koyo part numbers

Figure © Koyo, clipped unaltered from Koyo Ball & Roller Bearings catalog B2001E-6 — Standard Bearings section (B2001E-6b). It illustrates the product family printed there, which may include other sizes. Removed on request.

Koyo ML1204 — catalogue photograph of the deep groove ball bearing familyKoyo ML1204 — catalogue drawing of the deep groove ball bearing family
Koyo ML1204: bore d 1.2 mm, outside diameter D 4 mm, width B 1.8 mm, drawn to scaled 1.2 mmD 4 mmB 1.8 mm
Drawing: BearingLookup, to the printed bore d, outside diameter D and width B cited in the specifications below; internal detail is illustrative; seals or shields, if any, are not shown.

Specifications

Bore d1.2 mm
Outside diameter D4 mm
Width1.8 mm
Basic dynamic load rating Cr0.140 kN
Basic static load rating C0r0.03 kN

All specifications: Verified printed in Koyo’s own catalogue
